8T-1885: ФИКСАТОР

Description:
A Single Tube P Clip is made to hold a single tube or pipe securely in place. Its P-shaped profile makes it simple to mount on a flat surface. Designed with the assembled type of clip for a single tube P shape it has multiple parts Top and bottom which are combined to hold the single tube with an internal locking clip With the aid of a screw or another fastening device, it is tightened around it.

Attributes:
• In the mating part clip can be tight on 12.7mm OD tubing when the legs of the clips are drawn together
• Manufactured to precise specifications and are built for durability, reliability, and safety
• Provided with an additional hole to fit a fastener of size M10 or 3/8"

Applications:
A Single Tube P Clip can be a useful tool for joining or securing parts together safely and effectively, and the design helps to maintain the alignment, mostly used in Cat 438 Backhoe Loader.

• Clamp Width (in): 0.98

• Material Description: Steel

• Clamp Width (mm): 25

• Width (mm): 25

• Diameter (in): 0.51

• Diameter (mm): 13

• Width (in): 0.98

• Length (in): 1.97

• Length (mm): 50

• Thickness (in): 0.1

• Thickness (mm): 2.5

• Material: Alloy Zinc,Carbon Steel
