651-6102: Drum Drive Support Plate

The Cylinder Mounting Plate is used to securely attach the shock absorber cylinder to the equipment's frame. This plate ensures that the shock absorber functions correctly by maintaining its position and alignment during operation. Proper installation and alignment of the mounting plate are necessary for the effective performance of the shock absorber unit.

Attributes:
• Provides a stable platform for securing the shock absorber cylinder.
• Ensures proper alignment of the shock absorber for optimal performance.
• Minimizes the risk of system failures due to shock absorber misalignment.

Applications:
The Cylinder Mounting Plate is installed at the interface between the shock absorber cylinder and the chassis in the equipment, securing the cylinder for stable operation.

• Inner Diameter (in): 14.45

• Inner Diameter (mm): 367

• Length (in): 50.39

• Length (mm): 1280

• Material: Steel,Structural Steel

• Thickness (in): 0.79

• Thickness (mm): 20

• Weight (kg): 93.21

• Weight (lb): 205.49

• Width (in): 22.05

• Width (mm): 560
