650-1830: Cabinet Structure Support Bracket

The Hexagonal Head Bolt secures the secondary fuel filter, which is necessary for removing impurities and contaminants from the fuel before it reaches the engine. It allows for easy installation and removal with standard tools and ensures a tight and secure fit, preventing fuel leaks and maintaining the integrity of the fuel filtration system.

Attributes:
• Ensures proper sealing and alignment of fuel components.
• Provides a reliable seal to prevent fuel leaks.
• Features a hexagonal head for easy tightening.

Applications:
The Hexagonal Head Bolt is located on the secondary fuel filter assembly within the fuel system and positioned to fasten the filter to the fuel system housing, ensuring a secure attachment and preventing any leaks and contamination.

• Height (in): 1.18

• Height (mm): 29.9

• Length (in): 3.94

• Length (mm): 100

• Thickness (in): 0.08

• Thickness (mm): 2

• Weight (kg): 0.1

• Weight (lb): 0.22

• Width (in): 0.98

• Width (mm): 25

• Material: Carbon Steel
