646-2161: Radiator Frame Liner

A Pressure Relief Valve is used to protect the hydraulic unit from excessive pressure build-up. It consists of a valve body, a spring-loaded valve unit, and an adjustable pressure setting unit. The relief valve is attached to the hydraulic circuit and is engineered to automatically open and allow fluid to bypass when the unit pressure reaches a predetermined set point.

Attributes:
• Provided with a pressure setting value of 27600 kPa at 38 L/min to prevent potential damage to the hydraulic unit
• Provided with a maximum rated flow value of 760 L/min for precise control over the fluid flow
• Provided with a maximum rated pressure value of 41000 kPa to ensure optimal performance even under high-pressure conditions

Applications:
A Pressure Relief Valve acts as a safety measure by preventing excessive pressure build-up within the hydraulic unit, ensuring integrity and reliability, and safeguarding against potential damage or failure.

• Length (in): 7.13

• Length (mm): 181

• Material: Polyether Urethane Foam,Acoustical Insulation,Acr

• Thickness (in): 1

• Thickness (mm): 25.4

• Weight (kg): 0.01

• Weight (lb): 0.01

• Width (in): 2.36

• Width (mm): 60
