643-3549: Fender Mounting Plate

The Stick Cylinder Support maintains the stability and alignment of the stick cylinder during operation. It serves as the mounting point for the cylinder, facilitating the smooth operation of the stick. By securely holding the cylinder in place, this support helps transfer hydraulic force effectively, ensuring consistent performance and accurate control, contributing to the efficiency and reliability of the equipment during equipment tasks.

Attributes:
• Suitable for use with a 160-millimeter outer diameter stick cylinder.
• Protects the boom cylinder from misalignment issues.
• Provides stable support for the boom cylinder lifting operations.
• Reduces vibration and movement during operation.

Applications:
The Stick Cylinder Support is located at the base of the stick cylinder, providing necessary stabilization and ensuring robust support during equipment operations.

• Height (in): 5.91

• Height (mm): 150

• Length (in): 7.09

• Length (mm): 180

• Material: Steel,Structural Steel

• Thickness (in): 0.31

• Thickness (mm): 8

• Weight (kg): 2.87

• Weight (lb): 6.32

• Width (in): 5.12

• Width (mm): 130
