642-0614: Engine Oil Cooler Water Tube Assembly

The Screed Height Adjuster Indicator is used to provide real-time feedback on the screed's height adjustment. This indicator is mounted on the screed assembly, where it visually represents the current height setting through a calibrated arrangement. It functions by connecting to the height adjustment mechanism, allowing operators to monitor changes as they adjust the screed. Displaying the height measurement, helps the operator achieve the desired thickness of the asphalt being laid, which is necessary for ensuring the final surface meets quality standards.

Attributes:
• Integrates seamlessly with screed adjustment mechanisms.
• Offers accurate height measurements for optimal screed settings.
• Contributes to accurate leveling and surface consistency.

Applications:
The Screed Height Adjuster Indicator is mounted on the screed control mechanism to provide accurate information on the height setting of the screed during paving operations.

• Inner Diameter (in): 3.37

• Inner Diameter (mm): 85.6

• Length (in): 20.87

• Length (mm): 530

• Outer Diameter (in): 3.5

• Outer Diameter (mm): 88.9

• Radial Thickness (mm): 1.65

• Weight (kg): 1.83

• Weight (lb): 4.03
