632-3182: 9.5mm Thick Terminal Strip Mounting Bus Bar

The Quick Coupler Crank Linkage Rod is used to link the cranks that facilitate the engagement and disengagement of different attachments on the equipment. The rod ensures that the cranks operate in harmony, translating rotational motion into linear force to lock and unlock the quick coupler mechanism securely. As the equipment operator engages the quick coupler, the connecting rod transmits the necessary force to the cranks, ensuring a tight and secure fit of the attachment, thereby preventing accidental disengagement during operation.

Attributes:
• Ensures proper alignment and positioning of the quick coupler linkage.
• Provides structural reinforcement for the quick coupler mechanism.
• Resistant to vibrations and shocks, ensuring it remains properly positioned during operation.
• Ensures smooth transmission of motion between components.

Applications:
The Quick Coupler Crank Linkage Rod is used in the quick coupler system of the equipment, located within the coupling mechanism to connect cranks that engage and disengage attachments.

• Height (in): 5.15

• Height (mm): 130.7

• Hole Size (in): 0.43

• Hole Size (mm): 11

• Length (in): 3

• Length (mm): 76.2

• Material: Copper,Alloy Copper

• Thickness (in): 0.37

• Thickness (mm): 9.5

• Weight (kg): 1.03

• Weight (lb): 2.26

• Width (in): 2.5

• Width (mm): 63.5
