630-7325: 6mm Thick Fuel Filter Mounting Bracket

The Perception Pointer Plate provides accurate alignment and calibration for different equipment components. Offering a reliable reference point ensures that parts are correctly positioned, which is necessary for maintaining equipment efficiency and precision. This plate facilitates the fine-tuning of components, allowing for adjustments that enhance the overall performance and functionality of the equipment. Its design supports different adjustment procedures, making it a necessary tool for maintenance and setup tasks. Ensuring that parts are aligned according to specifications to prevent misalignments that otherwise lead to inefficient operation and damage.

Attributes:
• Provides a stable reference point for accurate alignment.
• Enhances operational efficiency by ensuring correct component alignment.
• Enhances measurement accuracy and reliability.

Applications:
The Perception Pointer Plate is used for accurate alignment and adjustment of components, ensuring accurate positioning during assembly and maintenance of equipment.

• Hole Size (in): 0.27, 0.51

• Hole Size (mm): 6.8, 13

• Internal Thread: M8x1.25

• Overall Height (in): 4.33

• Overall Height (mm): 110

• Overall Length (in): 6.42

• Overall Length (mm): 163

• Overall Width (in): 1.82

• Overall Width (mm): 46.2

• Thickness (in): 0.24

• Thickness (mm): 6

• Weight (kg): 0.95

• Weight (lb): 2.09

• Material: Structural Steel,Alloy Mixed
