622-3713: Battery Box Cover

The Power Train Oil Lines Mounting Plate is used to stabilize and support oil lines within the powertrain assembly. This mounting plate ensures that oil lines are securely fastened, preventing unwanted movement and vibration that leads to wear or potential damage. By keeping the oil lines in place, the mounting plate ensures that the oil flows efficiently and reaches all necessary components within the powertrain, thus contributing to the smooth operation of the equipment.

Attributes:
• Provides secure attachment points for oil lines.
• Prevents movement of oil lines due to vibrations during operation.
• Facilitates proper routing of oil lines.

Applications:
The Power Train Oil Lines Mounting Plate is located within the powertrain assembly and serves to stabilize and secure the oil lines, ensuring efficient fluid distribution.

• Hole Size (in): 0.53

• Hole Size (mm): 13.5

• Internal Thread: M10x1.5, M12x1.75

• Overall Height (in): 19.34

• Overall Height (mm): 491.2

• Overall Length (in): 50.02

• Overall Length (mm): 1270.5

• Overall Width (in): 8.07

• Overall Width (mm): 205

• Thickness (in): 0.2

• Thickness (mm): 5

• Weight (kg): 23.21

• Weight (lb): 51.17

• Material: Alloy Mixed
