615-4882: Auxiliary Hydraulic Lines Mounting Bracket

The Relay Mounting Plate firmly holds relays in position and prevents accidental disconnections and damage that disrupt electrical circuits. The plate features multiple mounting holes and slots that allow for easy installation and adjustment, ensuring that relays remain securely attached even during intense operation, ensuring durability and reliability, and making it a key part of the equipment electrical system, where proper relay function is necessary for overall performance and safety.

Attributes:
• Reduces the risk of electrical shorts or interference.
• Facilitates accurate alignment of relay pins and connectors.
• Ensures reliable performance under high load conditions.
• Provides resistance to vibrations, maintaining relay stability during operation.

Applications:
The Relay Mounting Plate is used in the electrical system of the equipment, found within the control panel and electrical compartment, it securely holds relays in place, ensuring stable and reliable operation of the equipment's electrical components.

• Hole Size (in): 0.39, 0.43

• Hole Size (mm): 10, 11

• Internal Thread: M8x1.25

• Overall Length (in): 15.34

• Overall Length (mm): 389.5

• Overall Width (in): 4.72

• Overall Width (mm): 120

• Thickness (in): 0.2

• Thickness (mm): 5

• Weight (kg): 0.78

• Weight (lb): 1.73

• Material: Alloy Mixed
