613-5725: 5mm Thick Generator Set Enclosure Channel

The Front Wiring Harness integrates and routes multiple electrical connections within the equipment chassis. This harness ensures seamless communication between the warning lamps, power sensor, tail lamp, lift kick-out solenoid switch, and bucket position solenoid switch. The harness provides a reliable conduit for power and signal transmission. It is routed along the chassis to maintain a neat and organized wiring layout, reducing the risk of damage and interference. Consolidating these electrical connections into a single harness simplifies installation and maintenance while ensuring optimal performance of the connected components.

Attributes:
• High-quality wiring for optimal conductivity.
• Provides stable electrical power transmission with minimal signal loss.
• Equipped with secure connectors that ensure reliable and stable connections.
• Heat-resistant insulation for longevity.
• Ensures accurate and reliable data transmission for operational monitoring.

Applications:
The Front Wiring Harness is used to connect the warning lamps, power sensor, tail lamp, lift kick-out solenoid switch, and bucket position solenoid switch, ensuring that each component receives the necessary electrical signals and power, facilitating their proper operation.

• Height (in): 4

• Height (mm): 101.6

• Hole Size (in): 0.5

• Hole Size (mm): 12.8

• Internal Thread: M10x1.5

• Length (in): 116

• Length (mm): 2946.4

• Thickness (in): 0.2

• Thickness (mm): 5

• Weight (kg): 18.82

• Weight (lb): 41.49

• Width (in): 2

• Width (mm): 50.8

• Material: Structural Steel,Alloy Mixed
