606-1522: Demountable Rim

The Boom Cylinder Guard Cover Guide is used to safeguard the boom cylinder and facilitate the smooth movement and proper alignment of the guard cover as it encases the boom cylinder, preventing debris, dust, and other particles from entering and causing potential damage. It also helps in absorbing impacts and reducing wear and tear on the cylinder, thereby enhancing the overall durability and performance of the equipment.

Attributes:
• Provides a stable pathway for the guard cover's movement.
• Supports the smooth operation of the boom under high loads.
• Ensures proper alignment of the boom cylinder guard cover.
• Helps in maintaining the structural integrity of the boom cylinder guard cover.

Applications:
The Boom Cylinder Guard Cover Guide is located within the boom cylinder cover assembly to guide and secure the guard cover and prevent debris, dust, and other particles from entering the cylinder.

• Hole Size (in): 0.87

• Hole Size (mm): 22

• Inner Diameter (in): 8.7

• Inner Diameter (mm): 221

• Length (in): 5.81

• Length (mm): 147.6

• Material: Steel,Alloy Steel,Carbon Steel

• Weight (kg): 85.26

• Weight (lb): 187.97

• Width (in): 16.35

• Width (mm): 415.4
