604-8547: Swing Drive Motor

The Swing Drive Motor serves as the powerhouse for the rotational movement of equipment, such as excavators. It operates by converting hydraulic pressure into mechanical energy, propelling the swing mechanism to rotate the upper structure of the excavator. This rotational motion is necessary for different operations, including digging, lifting, and positioning of materials. By controlling the speed and direction of rotation, operators can accurately navigate the excavator, optimizing productivity and safety on job sites. The durability and reliability of the Swing Drive Motor ensure consistent performance even under demanding working conditions, making it an integral component of equipment.

Attributes:
• Compact design.
• High torque output.
• Quick response time.
• Excellent load-bearing capacity.
• Weather-resistant build.

Applications:
The Swing Drive Motor is used to enable accurate and controlled rotation of the excavator's upper structure, facilitating versatile operations such as digging, lifting, and material placement.

• Overall Length (mm): 222.00

• Overall Length (in): 8.74

• Overall Height (mm): 210.00

• Overall Height (in): 8.27

• Overall Width (mm): 117.30

• Overall Width (in): 4.62

• Approx. Weight (kg): 15.30

• Approx. Weight (lb): 33.7

• Material: Ductile (Spheroidal) Iron
