585-1555: Joystick Mounting Bracket

A Supporting Bracket used in Auxiliary Hydraulic Lines is used to secure and guide the Hydraulic Lines connected to the Cylinder which is responsible for controlling the movement of the stick, allowing it to extend, retract, and tilt. The hydraulic lines support bracket ensures that the hydraulic hoses and lines remain securely in place, protecting them from damage and improving overall safety and efficiency.

Attributes:
• Withstand the vibrations and stresses encountered during the operation
• Provided with welded nuts of thread size M8 for secure fastening connection

Applications:
A Supporting Bracket used in Auxiliary Hydraulic Lines is used to hold the Hydraulic hoses in place and prevent them from getting tangled and sagging against the components.

• Overall Length (mm): 250.8

• Overall Length (in): 9.87

• Overall Height (mm): 142.6

• Overall Height (in): 5.61

• Overall Width (mm): 69

• Overall Width (in): 2.72

• Material: Carbon Steel,Alloy Steel,Alloy Mixed

• Color: Medium Gloss Black

• Weight (kg): 1.04

• Weight (lb): 2.29
