583-4885: Extendable Stick Wear Pad

The Pull Down Cylinder Rod is used to transmit the force generated by the cylinder to the pull-down system, enabling controlled and efficient movement. It handles the mechanical stresses and forces involved, providing reliable operation over time. By maintaining proper alignment and force transfer, the rod helps achieve smooth and accurate motion for operations that involve lifting, lowering, and positioning tasks.

Attributes:
• Transmits force from the cylinder to the pull-down mechanism.
• Maintains proper alignment for effective operation.
• Capable of handling high axial loads during operation.
• High tensile strength to endure high pulling forces.

Applications:
The Pull Down Cylinder Rod is positioned within the pull-down cylinder assembly, where it connects to the piston and other components to transmit force from the cylinder to the pull-down mechanism, enabling effective motion control.

• Material: Plastic,Nylon, 6, 6/12, 6/6 Plastic

• Outer Diameter (in): 2.52

• Outer Diameter (mm): 64

• Weight (kg): 0.14

• Weight (lb): 0.31

• Width (in): 1.73

• Width (mm): 44
