567-4715: Hydraulic Coupler Lines Support Plate

The Track Link Master Thrust Ring helps to maintain the correct tension and alignment of the track by ensuring that the track links move in a controlled path around the sprockets and idlers. It is situated within the bore of the track link, where it interfaces with the cylindrical surface of the track pin. This creates a bearing surface that allows for the pivotal movement of the track link relative to the pin. This movement is for the continuous loop formation and operation of the undercarriage.

Attributes:
• Providing a precise fit that minimizes play and movement within the track system
• Ensures the tracks maintain proper alignment during operation, reducing wear on related components

Applications:
The Track Link Master Thrust Ring is aligned to ensure that it does not introduce additional friction or stress points, which could lead to premature wear or failure. It acts as a bearing surface, preventing excessive wear on the track links and other components by distributing the forces evenly.

• Length (in): 6.69

• Length (mm): 170

• Material: Steel,Structural Steel

• Thickness (in): 0.39

• Thickness (mm): 10

• Weight (kg): 1.35

• Weight (lb): 2.97

• Width (in): 0.71

• Width (mm): 18
