566-6095: 342.5mm Inside Diameter D-Ring Seal

The D-ring seal for the piston of parking and service brakes is used in braking systems. Shaped like a D-ring, it seals the brake piston within the cylinder, preventing brake fluid leakage and ensuring hydraulic pressure integrity, it facilitates smooth piston movement, enabling efficient engagement and disengagement of brake pads with the rotor.

Attributes:
• Enables smooth and efficient movement of the brake piston during engagement and disengagement
• Prevents brake fluid leakage, maintaining hydraulic pressure

Applications:
This D-Ring Seal ensures fluid-tight sealing, contamination protection, and smooth piston movement, enhancing the safety and reliability of vehicle braking systems.

• O-Ring Type: D-Ring

• Material: FKM,Fluoroelastomer (FKM) Rubber

• Material Description: FKM rubber is capable of service temperatures of

• Hardness (Shore A): 90

• Cross Section Direction: Curved Outside Diameter

• Inside Diameter (mm): 342.5

• Outside Diameter (mm): 358.82

• Cross Section Width (mm): 5.33

• Cross Section Height (mm): 8.16

• Coating: None

• Color: Black

• Color Notes: Actual D-Ring color may differ from image.

• Notes: Dimensions and material descriptions provided for

• Inside Diameter (in): 13.48

• Outside Diameter (in): 14.13

• Cross Section Width (in): 0.21

• Cross Section Height (in): 0.32
