543-5397: Hood Support Plate

The Grease Lines Tube Assembly is used to carry grease from the central lubrication system to different lubrication points within the equipment's stick assembly, its design ensures proper sealing and efficient grease delivery to each lubrication point. This tube includes connectors, fittings, and protective covers to prevent contamination and ensure reliable lubrication to prevent kinking and binding, ensuring proper lubrication of moving parts, reducing friction, and preventing premature wear and component failure.

Attributes:
• Provides leak-proof connections.
• Maintains structural integrity under varying temperatures.
• Smooth inner surface for optimal flow.
• Resilience to vibration and pressure fluctuations.

Applications:
The Grease Lines Tube Assembly is located on the hoe stick to transfer grease to lubrication points to ensure smooth operation of moving parts, reduce friction, and extend the lifespan of components.

• Overall Height (in): 21.85

• Overall Height (mm): 555

• Overall Length (in): 25.12

• Overall Length (mm): 638

• Thread: M10x1.5, M12x1.75, M6x1

• Weight (kg): 12.56

• Weight (lb): 27.69

• Material: Alloy Steel
