455-0081: СЕГМЕНТ ВЕДУЩЕГО КОЛЕСА

The Undercarriage Sprocket Segment is responsible for transferring power from the machine's engine to the tracks, which propel the vehicle forward or backward. It engages with the track chain, which is a series of interconnected metal links that wrap around the sprocket. The sprocket segment consists of a toothed wheel or drum with specially designed teeth that mesh with the track links. As the sprocket rotates, it drives the track chain, causing the vehicle to move. The design and quality of the sprocket segment are essential for ensuring smooth movement and maximizing the lifespan of the undercarriage system.

Attributes:
• 5 teeth equally spaced on a 67 Degree arc
• Made from high-quality, wear-resistant steel
• Heat treatment is done to improve hardness and toughness, making it more resistant to wear, bending, and fatigue

Applications:
This Undercarriage Sprocket Segment with 5 teeth provides traction and propels the bulldozer's tracks, enabling it to maneuver through rough terrains and perform heavy-duty tasks effectively.

• Sound Segment: No

• Relieved: No

• Track Pitch (mm): 190

• Material Type: Plain Steel

• Number of Sprocket Bolts: 5

• Number of Sprocket Teeth: 5

• Material: Boron Steel

• Bolt Thread Size: M16
