445-2548: 50mm Diameter Hydraulic Cylinder Linkage Pin

The Hydraulic Cylinder Linkage Pin serves as a pivotal connection, linking the cold planer control to the hydraulic cylinder. This pin ensures the smooth transmission of motion and force, allowing for accurate adjustments and operations. It maintains the efficiency and functionality of the equipment by ensuring that the control inputs are accurately relayed to the hydraulic system. This linkage pin withstands forces and repetitive movements, enhancing the operational integrity of the equipment.

Attributes:
• Resistant to repetitive mechanical movements.
• Ensures smooth transmission of motion.
• Smooth surface to reduce wear and friction.
• Resistant to deformation under high loads.

Applications:
The Hydraulic Cylinder Linkage Pin is used to connect the cold planer control to the hydraulic cylinder, facilitating efficient movement and control during operation.

• Pin Diameter (mm): 50

• Pin Diameter (in): 1.969

• Overall Length (mm): 548

• Overall Length (in): 21.575

• Overall Width (mm): 210.9

• Overall Width (in): 8.303

• Overall Height (mm): 234

• Overall Height (in): 9.21

• Hole Size (mm): 30, 51

• Hole Size (in): 1.181, 2.008

• Weight (kg): 14.03

• Weight (lb): 30.931

• Material: Carbon Steel,Alloy Zinc
