3K-0806: ПРУЖИНА

Description:
A Conical Compression Spring is placed between the button and steering column of the Horn unit. As the button is pressed it contacts the horn and once it is released the spring helps to push the button to its initial position. Compression Springs are used as they allow for more efficient energy storage methods and provide a smooth change in resistance over time.

Attributes:
• Manufactured to precise specifications and are built for durability and reliability
• Solid length of the spring is 9.52mm
• Helps to maintain their shape and stability

Applications:
A Conical Compression Spring is used in the Horn unit to retain the button after pressure is applied. this is widely used in Cat 120C, 120G, 120H, 12G, 130G, 135H, 140C, 140G, 140H, 143H, 14G, 14H, 160G, 160H, 163H, 16G, 16H and 24H Motor Grader, 518 Skidder, 922A, 922B, 924F, 944A and 966A Wheel Loader, TR13 Powertrain.

• Inner Diameter (in): 0.92

• Inner Diameter (mm): 23.26

• Length (in): 1.56

• Length (mm): 39.62

• Outer Diameter (mm): 26.4

• Outside Diameter (in): 1.04

• Spring Type: Compression

• Wire Size (in): 0.06

• Wire Size (mm): 1.57

• Material: Carbon Steel
