380-1093: ДАТЧИК ТЕМПЕРАТУРЫ

Description :
The Temperature Sensor for engine low oil pressure is a critical component that detects and monitors the temperature of the engine when oil pressure is low. It provides real-time data on engine temperature, alerting the operator or control system to potential issues. Designed for accuracy, the sensor helps prevent engine damage by triggering warnings or shutdowns in cases of overheating.

Attributes :
• Designed for durability and reliability in demanding engine environments.
• Prevents engine damage and failure due to insufficient lubrication or excessive heat.
• Monitors both engine temperature and oil pressure simultaneously.
• Triggers automatic engine shutdown in the event of low oil pressure and elevated temperature

Applications :
The Temperature Sensor is used to automatically monitor the temperature of the engine and detect low oil pressure. It is widely used in Cat C18 and C32 Engine (Piston), C18, C32, C4.4, and C7.1 Generator Sets.

• Connector: 4 Pin

• Hex Size (in): 0.87

• Hex Size (mm): 22

• Material: Stainless Steel

• Temperature (°C): -40°C to +150°C

• Temperature (°F): -40°F to 302°F

• Outer Diameter (in): 1.32

• Outer Diameter (mm): 33.6

• Overall Length (in): 14.94

• Overall Length (mm): 379.5

• Thread: M14 X 1.5

• Weight (kg): 0.3

• Weight (lb): 0.66
