375-2814: БЛОК КЛАПАНА ТОРМОЗНОГО

The Hydraulic Brake Control Valve regulates brake pressure within the hydraulic brake unit of the equipment. It achieves this by controlling the flow of hydraulic fluid to the brake actuators, enabling accurate braking action according to the operator's input, It ensures safe and effective braking performance, contributing to overall operational safety.

Attributes:
• Enables accurate control and modulation of braking force.
• Built to withstand high pressures and harsh operating conditions.
• Adjustable brake pressure setting of 8790±350 kPa with an inlet pressure of 11722 kPa and 15 CSt oil.
• Brake pressure setting of 8687 +450 or -350 kPa (approximately 103 kPa less than AI).
• Pressure Requirement for Port A2 8790±1380 kPa with Al at 0 kPa and the pedal fully applied.
• Capable of handling a maximum inlet pressure of 20685 kPa.
• Suitable for ambient temperatures ranging from -40°C to 50°C.
• Operates with an ISO 18/15 or better cleanliness standard to ensure the integrity and longevity of the hydraulic brake unit.
• Designed for use with mineral-based hydraulic fluids (HYDO IOW).

Applications:
The Hydraulic Brake Control Valve is utilized during braking operations, to facilitate efficient fluid flow and pressure regulation, where it modulates brake pressure to achieve controlled deceleration and stopping of the equipment.

• Material: Ductile (Spheroidal) Iron
