346-3622: 1/4" Pop-Off Relief Valve

The Pop-Off Relief Valve operates within the regulator assembly by releasing pressure when a specified limit is reached, preventing the system from over-pressurizing. This valve is needed to maintain pressure balance while charging the accumulators with high-pressure nitrogen gas, preventing damage to the components. As the gas enters the regulator assembly, the valve monitors pressure levels, and when it exceeds the threshold, the valve "pops" open to release the excess, ensuring that the pressure stays within the desired range. This function safeguards the entire assembly and maintains proper performance during operation, making it a necessary element for effective pressure regulation.

Attributes:
• Withstands a maximum flow rate of 6 gallons per minute.
• Operates at high-pressure levels, suitable for nitrogen gas applications.
• Pop-off action occurs only when the pressure limit is exceeded.
• Equipped with a 3/4-inch barb for secure hose connection, minimizing leakage risks.
• Features a 1/4-inch inlet port that ensures accurate pressure relief control.

Applications:
The Pop-Off Relief Valve provides a controlled and safe release of excess pressure within the regulator assembly during the gas charging process, ensuring pressure regulation while charging accumulators with high-pressure nitrogen gas.

• Weight (kg): 0.1

• Weight (lb): 0.22

• Length (mm): 66

• Length (in): 2.598

• Hex Size (mm): 18.9

• Hex Size (in): 0.744

• Thread: 1/4" NPT

• Material: Brass,Alloy Copper
