237-9608: Aftercooler Plate Mounting Bar

An Aftercooler Plate Mounting Bar is used to secure aftercooler plates in place during the assembly process. This component applies the necessary preload to ensure a proper fit and alignment of the aftercooler plates. By maintaining consistent pressure, the mounting bar facilitates a more efficient and accurate assembly, reducing the risk of misalignment and damage. Its design helps streamline repair and maintenance procedures, contributing to overall equipment reliability and performance.

Attributes:
• Facilitates the secure installation of aftercooler plates.
• Facilitates faster and more efficient repair work.
• Ensures accurate alignment of aftercooler plates for effective function.

Applications:
An Aftercooler Plate Mounting Bar is used in the assembly of aftercooler plates within the equipment, it applies the necessary preload to ensure correct plate positioning and alignment.

• Outer Diameter (mm): 76.2

• Outer Diameter (in): 3

• Overall Length (mm): 270.1

• Overall Length (in): 10.634

• Hex Size (mm): 19.05

• Hex Size (in): 0.75

• Thread: 1-1/8"-7-2A, 5/8"-11-2A

• Weight (kg): 1.802

• Weight (lb): 3.973

• Material: Carbon Steel,Coating Mixed
