143-3158: РАЗЪЕМ

A Straight Adapter, in the context of connectors or fittings, typically refers to a device that allows for a direct, straight connection between two components without any angular or offset deviation. It is used to join or adapt different types of connectors, pipes, or hoses, enabling a seamless flow of fluids and gases.

Attributes:
Manufactured to a precise specification and are built for durability, reliability, and productivity.
End Conforms to SAE J1926-3 Light Duty Straight Thread O-Ring Male.
Maximum Working Pressure 690kPa

Applications:
A Straight Adapter is used to Connect the Cat® 120M, 12M, 140, 140M, 150, 16, 160, 160M, 16M, 18, and 18M Motor Grader, 2864C and 586C Tree Harvester, 320D, 323D, 336, 336E, 336F, 340, 340F, 345, 349, 349D, 349E, 349F, 352, 352F, 355, 373, 374E, 374F, 390E, 390F and 568 Excavators, 416, 416C, 416D, 416E, 416F, 420, 420D, 420E, 420F, 422F, 424, 424D, 426C, 428D, 428F, 430D, 430E, 430F, 432D, 432E, 432F, 434E, 436C, 438D, 442D, 442E, 442F, 444E, 450E, and 450F Backhoe, 420D Oem Applications, 621H, 623H and 627H Wheel Tractor Scrapers, 735B and 740B Articulated Truck, 777 and 777G Truck, 854 and 854K Wheel Type Tractor (For Dozer), 902, 906, 908, 914, 914K, 914M, 918M, 920, 920K, 950K, 950L, 950M, 962K, 962L, 962M, 966, 966F, 966L, 966M, 972L, 972M, 980H, 980K, 980L, 980M, 982M, 992, 992K, 993, 993K and IT62K Wheel Loader, C32 Engine-General Platform (C32), C9.3 Engine-General Platform (C9), MD5110, MD5150, and MD6640 Drills, MH3037, MH3049, MH3260, MH3275, and MH3295 Material Handler, PM3, PM310, PM312, PM313, PM6, PM620, PM622, PM8, RM400, RM600, and RM800 Paving Equipment.

• Transmission and Hydraulic Oil Compatibile Seal: 2M-9780 (7/8-14)

• Hex Size (in): 1

• Hex Size (mm): 25.4

• Oil and Fuel Compatible Seal: 238-5081 (7/8-14)

• Length (in): 2.4

• Coolant and Urea Compatible Seal: 6V-3251 (7/8-14)

• Length (mm): 61

• Thread: 7/8-14

• Weight (kg): 0.08

• Weight (lb): 0.17

• Material: Carbon Steel,Alloy Steel
