098-5653: Сферическая головка шатуна

Description:
Cat® spherical rod ends are manufactured for long service life, minimal maintenance, and high operational reliability. Spherical rod ends provide a mechanical articulating joint that accommodates oscillation during slow rotation. These joints also accommodate misalignment between the rod end and the attached shaft. Spherical rod ends consist of an eye-shaped head with an integral shank that forms the housing for a spherical bearing. Bearings reduce friction and provide protection between mating parts. They are specifically designed for low to medium speed, high load applications with little to medium side thrust.

Attributes:
• Length: 66.7 mm (2.625 in)
• Thread Size: M16
• Thread Length: 40 mm (1.574 in)
• Material: Steel
• Large load capacity
• Easy mounting and dismounting
• Suitable for heavy static or alternate loads, and shock loads

Application:
Cat spherical rod ends are typically used in rod and linkage assemblies and control groups where strength and flexibility are crucial.

• Diameter (mm): 37.9

• Material Description: Steel

• Тип головки шатуна: Сферический

• Диаметр головки штока — B (мм): 37,9

• Thread Size (mm): M16

• Thread Length (mm): 40

• Расстояние до отверстия под палец — A (мм): 66,7

• Высота — C (мм): 21,0

• Length to Pin Hole - A (in): 2.625

• Diameter - B (in): 1.492

• Height - C (in): 0.826

• Thread Length (in): 1.574

• Rod End Diameter - B (in): 1.49

• Диаметр штока (мм): M16

• Material: Alloy Steel
